| MODEL | BMW S 1000XR |
|---|---|
| ENGINE TYPE | Four stroke, transverse four cylinder, DOHC, valve actuation via single rocker arms , 4 valves per cylinder, Intake/outlet mm 33.5/27.2 |
| Year | 2019 |
| Displacement / Capacity | 999 cc / 60.9 cu-in |
| Bore X Stroke | 80 x 49.7 mm |
| Compression Ratio | 12.0:1 |
| Cooling System | Liquid Cooled |
| Max Power | 121 kW / 165 hp @ 11000 rpm |
| Max Torque | 112 Nm / 11.4 kgf-m / 83 lb-ft @ 9250 rpm |
| Mixture Control | Electronic injection, throttle valve 48 mm |
| Engine Management | BMS-X |
| Start System | Electric |
| TRANSMISSION SPECS | |
| Lubrication | Wet sump |
| Gear Box | Constant -mesh 6-speed gearbox, straight-toothed |
| Clutch | Multi-disc anti-hopping oil-bath clutch, mechanically operated |
| Primary / Final Drive | Final Drive : Chain Primary Ratio : 1.652 |
| Transmission Ratio | 2.647 |
| Gear Ratio | 1st 2.647 / 2nd 2.091 / 3rd 1.727 / 4th 1.500 / 5th 1.360 / 6th 1.261 |
| CHASSIS SPECS | |
| Frame | Construction type aluminium perimeter frame, engine self-supporting |
| Front Suspension | Upside-down telescopic fork, stanchion diameter 46 mm, adjustable for bump and rebound optional: Dynamic ESA |
| Rear Suspension | Aluminium double-strut swing arm with central spring strut, adjustable for rebound, optional: Dynamic ESA |
| Brakes | Front Brakes: 2 x 320 mm Discs, 4 piston calipers, ABS Pro. (dynamic brake light currently for EU markets only). Rear Brakes : Single 220 mm disc, 1 piston caliper, ABS Pro . (dynamic brake light currently for EU markets only). |
| Traction Management | |
| Emission Control | Closed-loop 3-way catalytic converter |
| DIMENSION SPECS | |
| Overall Length | 283 mm / 85.9 in |
| Seat Height | 840 mm / 33.1 in |
| Overall Height | 1408 mm / 45.4 in |
| Overall Width | 940 mm / 37.0 in |
| Overall Weight | Dry Weight - Wet Weight - 228 kg / 502.6 lbs |
| Wheelbase | |
| Inner Leg Curve | |
| WHEEL SPECS | |
| Wheels / Rims | Front Wheel : Rear Wheel: |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 190/55 ZR17 |
| Front Wheel Travel | 150 mm / 5.9 in |
| Rear Wheel Travel | 140 mm / 5.5 in |
| Castor | 117 mm / 4.6 in |
| Steering Angle | 64.5° |
| FUEL SYSTEM | |
| Fuel Capacity | 20 Litres / 5.2 US gal |
| Fuel Reserve | 4 Litres / 1.1 US gal |
| Fuel Consumption | |
| CAPACITIES | |
| Engine oil | |
| Brake fluid | |
| Top Speed | 274 km/h (170 mph) (estimated) |
